PJSC “Kramatorsk Heavy Duty Machine Tool Building Plant” is one of leading manufacturers of machine-tool equipment.
The technique, qualified engineering staff of the company make possible to manufacture a wide range of up-to-date equipment, advanced machine models with the application of up-to-date components and numerical control systems as well as spare parts and equipment for metallurgy, metal mining industry, machine building and power industry.
The extensive reconstruction and modernization of production are carried out in the company. The up-to-date high-technology equipment is purchased – high-production machining centers of leading international manufacturers: milling machining centers TOS-KURIM model FRFQ 350-VR/A12 and WALDRICH SIEGEN model PF-H-125-150; milling-boring machining center MECOF model CS50; boring machining center PAMA model Speedram 2000; heavier-duty grinding machine type GIORIA OD/ID model R/163 – 5000 x 500 with CNC and other manufacturing equipment due to which PJSC has considerably enhanced its technological capabilities, that gives an opportunity to establish manufacturing of up-to-date wind turbines along with foreign partners.
PJSC “KZTS” production includes the following branches:
Mechanical assembly production enables to use high-performance technologies and to carry out machining of parts, machines and mechanisms of different classes and dimension types: turning, vertical turning, boring turning, jig boring, milling, gear milling, gear shaping, gear grinding, planing, slotting, grinding and drilling of holes. Machinery of the company includes equipment which makes possible to carry out turning of workpieces with diameter up to 4000 mm and length up to 20 m, grinding of workpieces with diameter 1000 mm and length up to 5000 mm. It is possible to process workpieces with diameter up to 5000 mm and height up to 2500 mm on vertical turning machines. Gear-milling machines make possible to carry out gear cutting up to 45 module. Foundry of mechanical assembly production manufactures shaped castings made of cast iron brands GG15, GG20, GG30 АЧС-1 weighing up to 12 ton; and up to 7,5 ton of cast iron ВЧ500-2, ЧХ 0.5. The company has a wide experience of manufacturing of cooling plates made of cast iron brand ЧХ 0.5 for blast-furnace lining. Also it is possible to manufacture castings made of bronze О5Ц5С5, А9Ж4Л, О10Ф1, О10Ф0.5 and aluminium AK7 weighing up to 100 kg. Pattern shop manufactures models of any complexity for production needs. The equipment of heat treatment and electrodeposit coating area enables to perform the following operations: annealing, normalization, gas carburizing, nitriding, HFC hardening, chemical oxidation, galvanization and chronium plating. Assemble-welding production manufactures a wide range of mid-size and large-size metal structures made of light-gage and heavy-gage sheet metal, round bar and rolled section, bent pipes and shells. A new assemble-welding line consisting of four-roll sheet bending machine < b> Faccin 4HEL/S3170 , unit for assembly and welding of shells PEMA 80000HTMLS and welding crane CAB 460C is installed within the scope of modernization.
Main technological capabilities of PJSC “KZTS”
Blank production
Foundry production
| Sl. No. | Material of castings | Max. dimensions of castings, mm | Weighing of castings, kg |
| 1.1.1. | Gray cast iron GG15; GG20; GG30; АЧС | 5500×2000×2000 | 1…18000 |
| 1.1.2. | High-duty cast iron ВЧ 500-2 | 5500×2000×2000 | 1…12000 |
| 1.1.3. | Bronze О5Ц5С5; А9Ж4Л; О10Ф1; О10Ф0.5 |
500×500×500 Centrifugal up to Ø500 |
1…100 |
Assemble-welding production
| Sl. No. | Type of works | Main specifications | Notes |
| 1.2.1. | Manufacturing of metal structures | Unit weight up to 50000 kg | Productive capacity – 780000 kg/year |
| 1.2.2. | Gas cutting |
Max. dimensions of sheet – 3500×14000 mm Cut thickness – up to 300 mm |
Cut accuracy – 0,3…1 mm |
| 1.2.3. | Plasma arc cutting |
Max. dimensions of sheet – 3600×14000 mm Cut thickness – up to 30 mm |
Cut accuracy – 0,2…0,5mm |
| 1.2.4. | Rolling |
Ø250 mm…Ø5000 mm Max. thickness – 95 mm at width ≤ 1000 mm Max. width – 3000 mm at thickness ≤ 30 mm |
|
| 1.2.5. | Pipe bending | Up to Ø50 mm | |
| 1.2.6. | Sheet bending | Width up to 2000 mm, thickness up to 4 mm | |
| 1.2.6. | Sheet bending | Width up to 2000 mm, thickness up to 4 mm | |
| 1.2.7. | Pressing | Max. force – 100000 kg | |
| 1.2.8.. | Blanking | Max. force – 100000 kg |
Machining production
| Sl. No. | Type of works | Main specifications | Notes |
| 2.1.1. | Turning |
Ø10… Ø3600 mm; L = 20000 mm (turning machines); up to Ø5000 mm; Hworkpiece = 2500 mm (vertical lathes) |
Processing accuracy degree – 7…9 |
| 2.1.2. | Milling |
Max. workpiece dimensions (W×L×H) = 5000×14000×3900 mm. Qmax = 100000 kg Machines are equipped with CNC with capability of 5-coordinate processing |
Processing accuracy degree – 7…9 |
| 2.1.3. | Boring |
Dmax up to 2000 mm Lmax of boring up to 2000 mm Max. workpiece dimensions (W×L×H) = 4500×17000×5000 mm Machines are equipped with CNC system with capability of 5-coordinate processing |
Processing accuracy degree – 5…7 |
| 2.1.4. | Shaping and slotting |
Max. workpiece dimensions (W×L×H) = 2800×8000×2250 mm (shaping) (D×H) = 800×500 mm (slotting) |
Processing accuracy degree – 7…9 |
| 2.1.5. | Grinding |
Max. workpiece dimensions: Ø1000×5000mm (cylindrical grinding); Ø1500external×Ø1200internal×H640 mm (rotary grinding); Ø400internal, length 830 mm (internal grinding); (W×L×H) 800×1500×400 mm (face grinding); (W×L×H) 3200×16000×2500 mm (longitudinal grinding); Ø200 mm, L=1900 mm (thread grinding) |
Processing accuracy degree – 5…7 |
| 2.1.6. | Gear cutting and processing of splines |
M=30; Ø5200 mm; H=200 mm (gear milling); M=12; Ø800 mm; H=450 mm (gear shaping); M=12; Ø800 mm; W=120 mm (conical with circular-arc tooth); M=8; Ø500 mm; W=120 mm (conical with straight tooth); Ø500×2500 mm (spline milling); M=24; 120×120×1200 mm (rack milling); M=25; Ø1250 mm (gear grinding) |
Accuracy degree: 8-9 after edge cutting machining; 6-7 after grinding |
| 2.1.7. | Broaching |
External diameter of splines up to 260 mm; Max. broaching length – 220 mm |
Broaches for keyhole slots and spline opening with internal centering are available |
| 2.1.8. | Cutoff and sawing |
Max. workpiece section - 560×700 mm Max. workpiece length – 6000 mm |
With hydraulic clamping of workpiece |
